• Engine: John Deere 4039, 100 HP, 2100 RPM, 4 Cylinders, Turbo Charged, Fuel Efficient Engine
• Cutter bar width (ft): 14
• Threshing system: Rasp bar & Spike tooth
• Separation Type: Straw walker with 8 Wing Beater & Beater Grate
The self-cleaning radiator is a unique feature of the W70 Combine Harvesters. A cylindrical screen assembly is attached to the front side of the radiator, which enhances engine life by helping to prevent radiator choking.
The suction duct provided releases chaff and other foreign material normally held on the surface of the screen by a suction mechanism. It reduces the manpower that was required to clean the radiator.
The W70 Combine Harvesters are equipped with an electrically-operated reel speed adjustment. It is electrically controlled and consists of a variable-speed motor mechanism, enabling the operator to change the reel speed from the operator’s station with the help of a switch located on the instrument panel.
The operator can vary reel speed based on the crop conditions—down, tangled, wet, heavy weeds, heavy stemmed, tall and short crops.
Crop material is cut and gathered by the header, passes through the feederhouse drum, and then the feederhouse conveyor chain sends it to the threshing system.
The floating drum allows adjustments in height as per the crop mat coming from the header. This reduces choking and maximizes smooth flow of crop.
The W70 Combine Harvesters have a six-bat reel, which is a unique feature not available in other competitive combine harvesters in India.
The evenly structured large-diameter reel has six bats. The six-bat reel ensures even loading and avoids crop clogging.
The W70 Combine Harvesters are ergonomically designed. The tiltable steering column and adjustable operator’s seat give a comfortable driving experience and cause less fatigue to the operator, even in long hours of operation.
The seat can be adjusted up and down as well as forward and backward as per the operator’s comfort.
The W70 Combine Harvester is equipped with a reliable, fuel-efficient John Deere 4039 100-hp engine.
The powerful 4039 engine has good lugging power and in comparison to the competition, there is less rpm drop even at peak load conditions.
The four-speed transmission system optimizes the ground speed as per field and crop conditions and thus gives better mileage.
The W70 incorporates wobble box technology to operate the cutterbar, unlike the cam technology in competitive harvesters. The wobble box prevents vibration, thus reducing crop damage.
The W70 Combine Harvesters have a variable-speed ground drive with Posi-Torq mechanism in the lower unit. This mechanism helps the harvester to work even in moist and undulating fields, offering easy maneuverability. The engine drive transmits power to the ground drive’s upper unit and then to its lower unit.
Due to the automatic variation in variable speeds, the belt tension is managed well and helps the combine to work in moist and undulating fields, offering good maneuverability.
The cutterbar can be adjusted to mid, extended and retracted positions, enabling the combine to handle all crop conditions, which is especially important when there are lodged crops.
In the retracted position, the cutterbar works better in crops that are down and tangled or in crops with heavy weeds that can cause plugging.
The extended position is suitable for standing, tall, heavy-stemmed crops such as sorghum, tall wheat, and soybean as well as for very short, light, dry crops. This position enables material to fall and feed evenly under the platform auger. Its tilt angle is adjustable to 9 degrees.
The beater and beater grate is another unique feature of the W70 Combine Harvesters. The beater has eight wings and rotates on an axis parallel to the axis of the normal rotor and concave This increases threshing capacity significantly.
A large inertia drum and long concave separation area can easily be set to perform in a wide range of crops and conditions.
A speed differential between the crop and drum speed results in thorough initial threshing.
A large-diameter beater provides excellent material handling and additional separation as the second concave extends the separation area.
Specs & Compare
|Select up to 4 models to compare specifications||
W70 Combine Harvester
|John Deere 4039, 100 HP, 2100 RPM, 4 Cylinders, Turbo Charged|
|Rasp bar & Spike tooth|
|1020 mm x 610 mm|
|Straw walker with 8 wing beater and beater grate|
|4 Forward + 1 Reverse|
|Front||16.9x30, 12 PR|
|Rear||7.5x16, 12 PR|
|8190 mm X 4468 mm x 3400 mm|
|Paddy, Wheat, Soybean, Pulses etc|
Improvement in the product is a continuous process. Hence the information given here is subject to change without prior notice.
Accessories shown are not part of standard equipment. Please contact your nearest dealer for more detailed information.
